Key Features:

Parameter             Specification

Module Type                 OSFP

Operating                      Rate8×112 Gbps

Interface Bandwidth      DC to 50 GHz @ MPX50

Power Supply               External Input

Functional Interface      External Control

I2C Interface                 USB-to-I2C

MSA Protocol Support  Supports upper computer read/write operations

Compliant Standards    Compliant with SFF-8679, SFF-8024, IEEE 802.3ck, etc.

Additional Features:

1. Integrates multi-coaxial cable assemblies, 67 GHz SLC70 2×8 cables
2. DDMI connection (I2C)
3. Compliant with IEEE 802.3ck
4. High-performance signal integrity traces from SLC70 cables to OSFP host connectors
5. All 8-channel cables are phase-matched per group
6. Adopts high-performance PCB material
7. 800G OSFP MSA pinout

      Cage for 800G OSFP Modules

      Operating Temperature: -40℃ ~ +85℃
